Mission QX-1 MKII Two-way bookshelf speaker

$799.00

When selecting the best is the only option when overwhelmed by cheaper knock offs.

The Mission QX-1 MKII is a 2-way standmount/surround/bookshelf speaker featuring a 135mm bass driver and a 38mm textile ring dome tweeter.

Description

As per all Mission speaker concepts, the process of listening, listening and more listening is the key to improvement. With the added benefit of modern speaker design tools, such as computer-aided optimisation technology, crossover modeling, and laser interferometry, Mission engineers also spent much time fine tuning the crossovers, components, materials, and construction.

Much like the now-established and equally class-leading Mission LX MKII series, the QX MKII series takes an already phenomenal loudspeaker solution but refines it, optimises it, and brings even more vibrancy, finesse, and class, through a process of evolution, not revolution.

Design Features

  • Inverted Driver Geometry (IDG): Positions the treble unit below the bass/midrange driver to time-align sound waves at listener head height. [1, 2]

  • Ring of Fire Tweeter: Uses a ring dome with a fixed phase plug to reduce high-frequency distortion and improve detail.

Additional information

Colour

Lux Black, Lux White, Walnut Pearl

Specifications

General Description 2-way Bookshelf Speaker
Enclosure Type Bass Reflex
Transducer Complement 2-way
Bass Driver 5"(135mm) Long Fiber Composite Cone
Treble Driver 1.5"(38mm) Textile Ring Dome
AV Shield No
Sensitivity (2.0V @ 1m) 87dB
Recommended Amplifier Power 25-100W
Peak SPL 95dB
Nominal Impedance 4 Ω (compatible 8Ω)
Minimum Impedance 3.9Ω
Frequency Response (+/-3dB) 55Hz ~ 24kHz
Bass Extension (-6dB) 48Hz
Crossover Frequency 2.4kHz
Cabinet Volume (in litres) 8.1L
Height (on plinth) 280mm
Width 195mm
Depth (with terminals) (250+10)mm
Carton Size 520 x 345 x 380mm
Net Weight 6.2kg/pcs
Gross Weight 14.2kg/ctn
