Mission LX-3D Surround MKII

$1,199.00

LX-3D MKII is a 2-way Centre speaker with a 4″ bass driver and a 1″ softdome treble unit.

Description

Advanced New Driver Surrounds and Crossover

One of the critical areas highlighted by the development of Mission ZX and QX models was the use of serrations in the driver surrounds to help scatter interfering reflections from localised surfaces to the dome and cone. LX MKII now incorporates these serrations into the driver surrounds, adding further finesse to the drive unit outputs and providing a smoother frequency response.

With minor perturbations in the driver response ironed out, the crossover for each model has been optimised to take advantage of the improved performance. The result is that the LX MKII builds on the winning formula of the LX, both enhancing the clarity of midrange and treble detail and improving the micro-dynamics of the musical performance for an even more thrilling listener experience.

Inverted Geometry Drive Design

Mission’s classic IDG (Inverted Driver Geometry) driver format positions the high frequency below the bass / midrange driver meaning the length of path is equalised so the sound waves coincide at the listener’s head height. A proprietary principle that improves ‘time alignment’ and thus transient performance in Mission speakers.

Exceptional Sound at Affordable Prices

LX MKII is the epitome of affordable high-end audio, harnessing materials, techniques and technologies that you would only expect to find in other speakers costing many times the price. Whatever your choice of music, LX MKII will reproduce it with outstanding accuracy, detailing and realism,

Additional information

Colour

Lux Black, Lux White, Walnut Pearl

Specifications

  • General Description: 2-way surround speaker
  • Enclosure Type: Closed-box system
  • Transducer Complement: 2-way
  • Bass Driver: 4″ (100 mm) composite fibre
  • Treble Driver: 25 mm microfibre dome
  • AV Shield: No
  • Sensitivity (2.83 V @ 1m): 86 dB
  • Recommended Amplifier Power: 20 – 80 W
  • Peak SPL: 99 dB
  • Nominal Impedance: 8Ω Compatible
  • Minimum Impedance: 4.5Ω
  • Frequency Response (+/–3 dB): 105 Hz ~ 20 kHz
  • Bass Extension (–6 dB): 90 Hz
  • Crossover Frequency: 2.8 kHz
  • Cabinet Volume: 2.2 L
  • Height (on plinth): 158 mm
  • Width: 160 mm
  • Depth (with terminals): 260 mm
  • Carton Size: 365 × 345 × 245 mm
  • Net Weight: 2.85 kg/pcs
  • Gross Weight: 6.2 kg/ctn
  • Finish: Walnut Pearl / Lux White / Lux Black
