The 5.2 channel Denon AXR-X550BT AV receiver delivers quality home theater at an accessible price. Watch your favorite movies and shows with exceptional picture clarity thanks to Full 4k Ultra HD, Dolby Vision and HDCP 2.2 (supported on three of the five HDMI inputs). Stream music with built-in Bluetooth or play back MP3, WMA, FLAC and MPEG-4/AAC tracks via the front panel USB port. A guided Setup Assistant and measuring microphone make getting started as simple as possible. And with a more than 100-year history steeped in audio technology, the Denon AVR-X550BT is guaranteed to provide audio fidelity and picture clarity to vastly improve every aspect of your home theater.
Powerful 5-Channel Amplifier With ECO Mode
Featuring discrete high-current amplifiers on all channels, the AVR-X550BT delivers high-power performance at 130 Watts per channel (6 Ohms, 1kHz, 1% 1 Ch. Drive). Low impedance drivers provide operational stability for a wide range of speakers and create balanced, tonal sound. The AVR-X550BT features a five-input HDMI section with 4K/60 Hz full-rate pass-through and HDCP 2.2 support on three inputs.
GEARED UP FOR 4K ULTRA HD
The advanced HDMI video section of the AVR-X550BT lets you enjoy your favorite movies and shows with the best picture quality available.
BREATHE NEW LIFE INTO LEGACY SOURCES
The AVR-X550BT features an advanced HDMI section with 5 inputs that offer full 4K Ultra HD, HDR (High Dynamic Range), BT.2020, Wide Color Gamut, 4:4:4 Pure Color sub-sampling, as well as 21:9 and 3D video pass-through, Dolby Vision compatibility and HLG (Hybrid Log-Gamma) pass-through support. HDCP 2.2 is supported on 3 inputs for copy protected content.
SET-UP AND CONNECT WITH EASE
The included AVR-X550BT Quick Start Guide provides simple, clear instructions for how to get started. Once you connect your TV to the AVR-X550BT via HDMI, the exclusive Denon Setup Assistant appears on your TV screen to walk you through setup, step by step. A row of color-coded speaker connections is laid out horizontally, making organizing and connecting speaker wires simple. Plus, the AVR-X550BT comes with a measuring microphone that adjusts critical system parameters for top audio fidelity, custom-tailored for your speaker system and listening space.
SMART TV CONNECTIVITY
Control the Denon AVR-X550BT with your Smart TV remote via the HDMI CEC functionality associated with your Smart TV. Simply set “HDMI Control” to ON in your receiver, then set “Smart Menu” to ON and begin controlling the AVR-X550BT with your TV remote. The Smart Menu home screen provides you quick access to source and surround mode selections, the AVR’s setup menu and four Smart Selects.
Your favorite tracks, at your fingertips. Stream music from your computer or smart devices with the AVR-X550BT and built-in Bluetooth. It remembers up to eight paired Bluetooth devices, so invite family and friends to share their music and enjoy the audio quality of the AVR-X550BT. To stream via Bluetooth, simply select the Denon AVR-X550BT from the Bluetooth menu on your smart device.
DENON AVR REMOTE APP FOR SEAMLESS CONTROL
Better control in your back pocket. The Denon 500 Series Remote app for iOS and Android makes using the AVR-X550BT even easier —adjust volume, turn it on or off, mute the music, and select a source. Download the Denon 500 Series Remote app today.
QUICK SELECTS FOR USER-FRIENDLY AUDIO TUNING
The Denon AVR-X550BT front panel features four Quick Select buttons that store your preferred audio settings for each source. Switch between TV audio, Blu-Ray, media players and more, and the AVR-X550BT adjusts the EQ settings to your preferences for that media source. Use the buttons on the front panel or opt for the same Quick Selects on the AVR remote for faster control.
FRONT USB PORT FOR HIGH-RESOLUTION AUDIO
In addition to numerous analog and digital AV connectors, the AVR-X550BT features a USB port on the front panel for convenient audio playback. It’s compatible with a wide range of portable USB devices and supports MP3, WMA, FLAC and MPEG-4/AAC tracks. Whether you want to listen to your latest MP3 download or soak in the fidelity of audiophile-quality FLAC recordings, you have quick access to your favorite songs.
COMPATIBLE WITH DENON HEOS LINK
Connect the AVR-X550BT to the Denon HEOS Link (sold separately) for wireless music streaming and the ultimate in sound quality. The HEOS Link enables the AVR-X550BT to play back nearly unlimited online streaming services like Spotify, TIDAL, and more. With the HEOS Link, you can also add HEOS multi-room audio to your home theater audio system, and play different songs in different rooms or the same song in every room. Also available is is ability to control your HEOS experience with Amazon Alexa voice commands. Once connected, use the HEOS app to control the AVR remotely. Enjoy more music and flexibility with the same great Denon quality.
|Number of power amps||5|
|Power output||130 watts per channel
(6 ohms, 1 kHz, THD 1%, 1ch driven)
90 watts per channel
(6 ohms, 1 kHz, THD 0.7%, 2ch driven)
70 watts per channel (8 ohms,
20 Hz – 20 kHz, THD 0.08%, 2ch driven)
|Speaker impedance||6 – 16 Ω/ohms|
|Input sensitivity/impedance||200 mv / 47kΩ/kohms|
|Frequency response||10 Hz – 100 kHz — +1, –3 dB (Direct mode)|
|S/N Ratio||98 dB (IHF-A weighted, Direct mode)|
|Tuning frequency range FM||87.5 – 108 MHz|
|Tuning frequency range AM||522 kHz – 1611 kHz|
|Power supply||AC 230 V, 50/60 Hz|
|Power consumption||310 W
(Standby 0.1 W, CEC standby 0.5 W)
|Power consumption No-Sound||26 W (ECO Mode On)
35 W (ECO Mode Off)
|Dimensions (W x H x D)||17.1” x 5.9” x 12.6” in|
|Component (video) IN||–|
|Composite (video) IN||2|
|Analog Audio IN||2|
|Digital Optical / Coaxial IN||2 / 1|
|HDMI Monitor / Zone 2 OUT||1|
|Component (video) OUT||–|
|Composite (video) OUT||1|
|Audio Pre-out (SW) OUT||2.0 Ch|
|Zone 2 / Zone 3 Pre-out||–|
|Microphone Port||x 1|
|FM/AM Tuner Antenna||x 1|
|Remote Control In/Out||– / –|
