Description
Optimum imaging and set-up are established via a pivoting tweeter, high frequency (+3 dB / 0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.
| Frequency Response | 55 Hz – 30 kHz |
| Nominal Impedance | 6 ohms |
| Sensitivity (1W@1M) | 88.5 dB |
| Maximum SPL | 107.4 dBA |
| Power Handling (RMS) | 65 W |
| Recommended Amplifier Requirements | 20 – 65 W |
| Drive Unit Complement | 6 ½" C-CAM cone bass driver 1" C-CAM pivoting Gold Dome tweeter |
| Adjustment Controls | HF Level Switch (+3dB / 0dB / -3dB) Boundary Compensation Switch |
| Overall Diameter (Including Grille) | 370 x 250 mm (149/16 x 913/16") |
| Overall Depth (Including Grille) | 96 mm (33/4") |
| Mounting Depth | 92 mm (35/8") |
| Cut-Out Hole Diameter | 332 x 213 mm (131/16" x 83/8") |
| Fixing Type | 6 position Tri-Grip dog fixings |
| Construction Material | Mineral filled ABS, RoHS compliant |
| Weight | 2.26 kg (5 lb) |
| Pre-Construction Bracket | WB6 Pre-Construction Bracket (Purple) |
| Sold As | Single Unit |
